Product Overview
Introducing the Dual Wire Feed Handheld Fiber Laser Welder from GloryStar, offered exclusively through Omni Machine Inc. Available from 1.5 kW to 3 kW, this unit features a second wire feeder enabling programmable A/B/A+B wire feed sequences — run two different filler materials without swapping spools. Ideal for dissimilar metal joining, clad welding, or complex multi-pass work.
Same 1.5 lb wobble head, 0–8mm weld spot, wire support 0.8–2.5mm. Cleaning: 0–30mm standard, optional 0–120mm wide-scan. 10M fiber cable standard, customizable.
Key Features:
- 1.5 kW to 3 kW fiber laser power options
- Dual wire feed — programmable A/B/A+B sequences
- Handheld wobble head: 1.5 lbs (0.7 kg)
- Weld spot: line 0–8mm; Cleaning: 0–30mm (optional 0–120mm)
- Up to 4× faster than traditional welding
- Red light positioning, integrated water cooling
- Safety lock, laser safety glasses included
Technical Specifications:
| Specification | Value |
|---|---|
| Laser Power | 1.5 kW – 3 kW (1500W–3000W) |
| Fiber Length | 10M / 33’ standard (customizable) |
| Welding Head | Handheld wobble head (welding, cleaning, cutting) |
| Dual Wire Feeder | Programmable A/B/A+B modes |
| Wire Diameter | 0.8 / 1.0 / 1.2 / 1.6 / 2.0 / 2.5mm |
| Gun Weight | 1.5 lbs (0.7 kg) |
| Weld Spot Range | Line 0–8mm |
| Cleaning Range (Standard) | 0–30mm |
| Cleaning Range (Optional) | Line 0–120mm |
| Positioning | Red light |
| Cooling | Integrated water cooling |
| Shielding Gas | Argon, Nitrogen, Helium, CO2 blends |
| Power Supply (Native) | AC 220V (3kW: 380V) |
| Power Supply (U.S. with Transformer) | 240V 1-Phase or 480V 3-Phase, 60Hz |
Standard Accessories:
- Handheld wobble welding/cleaning/cutting head
- Dual automatic wire feeders
- Laser safety glasses
- Protective lenses
- Welding nozzle set (multiple types)
- Operating manual and documentation
Available Options:
- Wide-scan cleaning head (0–120mm)
- Extended fiber cable lengths
- Additional nozzle sets
- Step-up transformer for U.S. power
Warranty Information:
- Complete Machine: 1-Year Warranty
- Optical components, lenses, and consumables: Not covered
- Lifetime repair service available
- Phone response within 2 hours
- On-site service within 48 hours (continental U.S.)
- Lifetime free technical consultation and remote software updates
All warranty service provided through Omni Machine Inc. with direct support from GloryStar. Technical support available via phone, email, WhatsApp, and remote diagnostics. On-site service available within the continental United States.
All specifications subject to change without notice. European-native electrical specifications (380V 3-phase 50Hz) require step-up transformer for U.S. operation (480V 3-phase 60Hz). Contact Omni Machine Inc. for current pricing, lead times, and configuration details.
